id card printer
tp9200 card printer
- Easy to Print Photo ID Card
- Reliable to Encode Mag, Stripe/IC/RF Card
- Flexible Card Printer for the Daily Card Printing
id card printer
| item | detail | |
|---|---|---|
| Print Technology | Direct-to-card Dye-sublimation / Resin thermal transfer | |
| Print Capabilities | Single & Dual sided printing | |
| Full-color and monochrome printing capability | ||
| Print Resolution | 300 dpi (11.8 dpm), 16.7 Million Color | |
| Print Speed "Under specific condition" |
Single Side - more than 150 cards/hour | |
| Dual Side - more than 100 cards/hour | ||
| Monochrome up to 700 cards/hour | ||
| Card Capacity | Automatic Feed : 100-card input for 0.4mm ~1.2mm cards | |
| 70-card output standard | ||
| Manual Single Feed : 1-card input | ||
| Printer Option | Magnetic Stripe Encoding | ISO7811 (Track 1,2,3), Coercivity : HiCo/LoCo |
| Smart Card Personalization | ISO7816, EMV Level 1 (PS/SC, serial) and PBOC 3.0 certified | |
| RFID Card | Mifare, ISO 14443 A / B, Desfire, NFC, Felica (PC/SC or Serial) *Other encoding options are available upon request |
|
| SAM | PLCC 1 (Extra-1 Sockets), SIM 4 sockets | |
| Mobile Chip Card | ISO 7816 | |
| Printer Specifications |
Dimensions | Single : 403(L) × 192 (W) × 202 (H)mm |
| Dual : 471(L) × 192 (W) × 202 (H)mm | ||
| Weight | Single : 5.5kg / Dual : 6.5kg | |
| Power | 100-240V ~ 50/60Hz 1.7A / Output : DC 24V 3.75A | |
| Font | True Type Fonts via Window Drivers | |
| Memory | 128MB RAM | |
| Interface | USB2.0 (High-Speed), RS-232, Built in 10/100 Ethernet | |
| Operation System for Printer Driver |
Windows ®10/8.1/8/7/Vista/XP/Server 2012, 2012 R2, 2008, 2008 R2, 2003 | |
| Approvals | FCC Class A, CE (EN 55022 Class A, EN 55024), CCC, KCC, Energy STAR, RoHS | |
| Software | Card Designer™ | |
